PE250 * 400 Jaw Crusher

  • Model: PE250×400
  • Capacity:5-20TPH
  • Motor Powder15kw
  • Feed Opening(mm):250×400
  • Application Range:Primary and secondary crushing

Get a Quote Services Online

PE250 * 400 Jaw Crusher
  • Place of Origin:Henan China (Mainland)
  • Brand Name:Hongxing
  • Model Number: HX
  • Certificate:ISO9001:2008
  • Warranty: 12 Months
  • Color: Orange / white
  • Installation:under engineer's guidance
  • Delivery Means: Container

Jaw crusher is mainly used as coarse crusher and secondary crusher in mining, building materials, infrastructure, metallurgy, cement, and other industries. According to different swing methods of moving jaw plate, jaw crusher is classified into double toggle jaw crusher and single toggle jaw crusher. According to the width of feed opening, jaw crusher can be divided into large jaw crusher, medium jaw crusher and small jaw crusher.

PE250 * 400 Jaw Crusher

PE250 * 400 jaw crusher is a kind of single toggle jaw crusher as well as small/mini jaw crusher, which has such advantages as simple structure, reliable operation, easy to use and maintenance, etc. PE250 * 400 jaw crusher can crush materials with less than 250MPA comprehensive strength, and less than 210mm size, such as granite, limestone, quartz stone, sand, basalt, etc.

PE250 * 400 Jaw Crusher

Application Advantages of Jaw Crusher PE-250x400

1. The rack is fixed, which keeps highly efficient production of jaw crusher PE-250x400 under extreme pressure. Moreover, moving jaw, jaw plate and eccentric shaft of jaw crusher PE-250x400 are made of high manganese steel with good quality and high hardness, which are more durable and stable. That is the reason why PE250 * 400 jaw crusher is most popular with customers among various crushing machinery.

2. Compared with other types of crushing equipment, PE-250 x 400 jaw crusher has the biggest advantage of big crushing ratio, which can realize efficient crushing of both large materials and small materials. Besides, its crushing ratio can be adjusted so as to adapt to materials with different shapes, thus realizing highly efficient and stable production.

3. PE250 * 400 jaw crusher also has big production advantage on its discharge opening. A variety of stone crushers should be equipped with gasket when working. While this PE-250 x 400 jaw crusher shouldn't, you can only adjust the discharging opening accordingly, which is more convenient and efficient.

Jaw Crusher 250 x 400

4. Motor and crusher of jaw crusher Pe250 400 for sale are one, which occupies less space and can meet various production requirements of different users.

The application advantages of PE250 * 400 jaw crusher is very obvious, which can be seen from the above description. Actually, PE-250 x 400 jaw crusher adopts more advanced technology. In the production process of jaw crusher PE-250x400, operators should do a good job of maintenance in a timely manner while correct operating so as to ensure the equipment works efficiently and bring more benefits to enterprise.

If you need more information on our Jaw Crusher Pe250 400 for sale or have other concerns about our factory, please feel free to contact us, thank you!

Technical parameters of PE250 * 400 Jaw Crusher

Model
Feed opening
(mm)
Max.feeding size
(mm)
Adjusting range of discharge opening
(mm)
Processing capacity
(t/h)
Rotation speed of eccentric shaft
(r/min)
Motor power
(kw)
Total weight
(t)
Dimensions
(L×W×H)
(mm)
PE-150×250 150×250 125 10-40 1-3 250 5.5 0.8 720×660×850
PE-200×300 200×300 180 15-50 2-6 260 7.5 1.2 910×750×990
PE-200×350 200×350 180 18-70 3-10 260 11 1.5 1000×870×990
PE-250×400 250×400 210 20-60 5-20 300 15 2.8 1300×1090×1270
PE-400×600 400×600 340 40-100 16-60 275 30 7 1730×1730×1630
PE-500×750 500×750 425 50-100 40-110 275 55 12 1980×2080×1870
PE-600×750 600×750 500 150-200 80-240 275 55 15.8 2070×2000×1920
PE-600×900 600×900 500 65-160 50-180 250 55 17 2190×2206×2300
PE-750×1060 750×1060 630 80-140 110-320 250 110 29 2660×2430×2800
PE-800×1060 800×1060 640 130-190 130-330 250 110 29.8 2710×2430×2800
PE-830×1060 830×1060 650 160-220 150-336 250 110 30.7 2740×2430×2800
PE-870×1060 870×1060 660 200-260 190-336 250 110 31.5 2810×2430×2800
PE-900×1060 900×1060 685 230-290 230-390 250 110 33 2870×2420×2940
PE-900×1200 900×1200 750 95-165 220-450 200 110 52 3380×2870×3330
PE-1000×1200 1000×1200 850 195-265 315-500 200 110 55 3480×2876×3330
PE-1200×1500 1200×1500 1020 150-350 400-800 180 160-220 100.9 4200×3300×3500
PE-1500×1800 1500×1800 1200 220-350 500-1000 180 280-355 122 5160×3660×4248
PE-1600×2100 1600×2100 1500 300-400 1300-2200 160 350-380 150.6 6210×4013×4716
PEX-150×750 150×750 120 18-48 8-25 320 15 3.8 1200×1530×1060
PEX-250×750 250×750 210 25-60 13-35 330 30 5.5 1380×1750×1540
PEX-250×1000 250×1000 210 25-60 16-52 330 30 7 1560×1950×1390
PEX-250×1200 250×1200 210 25-60 20-61 330 37 9.7 2140×1660×1500
PEX-300×1300 300×1300 250 20-90 16-105 300 55 15.6 2720×1950×1600

Note: Please enter your demand such as Raw material type, Capacity, Feeding material size, Final product size, etc. To become our quality clients will have access to a discount of contract!
